GE PWB 68A993124-D邏輯控制器卡 PDF資料
1.產 品 資 料 介 紹：
中文資料：
PWB 68A993124-D 是一種邏輯控制器卡，常用于 GE（通用電氣）Speedtronic 系列控制系統以及其他自動化設備中。此卡的主要功能是執行邏輯控制任務，它能夠處理和控制系統中的信號流和指令傳遞，是工業自動化和過程控制系統中的關鍵組件。
產品特點
邏輯控制功能：
- 該卡通過內置的邏輯電路處理控制信號，執行各類決策和指令處理，確保系統按照預定邏輯順利運行。
高精度數據處理：
- 提供高精度的數據處理能力，支持實時計算和信號轉換，以保證系統的高效性和穩定性。
可靠性高：
- 設計用于惡劣的工業環境，具有高抗干擾性和耐用性，確保長期穩定運行。
靈活的信號接口：
- 提供多種輸入/輸出接口，支持不同類型的信號傳輸，包括數字、模擬信號等。
模塊化設計：
- 插卡式設計，便于在控制系統中集成、安裝和更換。
技術規格
工作電壓：
- 支持24V DC 或 48V DC 電源輸入（具體要求根據系統配置而定）。
邏輯處理能力：
- 內部包含處理單元，用于執行復雜的邏輯運算和數據流處理。
輸入/輸出：
- 支持多種信號類型的輸入和輸出，適用于不同的工業自動化需求。
- 典型的I/O接口包括數字輸入、數字輸出和模擬輸入/輸出等。
工作環境：
- 溫度范圍：-20°C 至 +70°C。
- 濕度范圍：0%-95%（無冷凝）。
接口類型：
- 多針連接器，用于連接系統中的其他模塊或外部設備。
尺寸和安裝：
- 通常具有標準化的尺寸，能夠適配 GE Speedtronic 系統的插槽，便于安裝和更換。
英文資料：
PWB 68A993124-D is a logic controller card commonly used in GE's Speedtronic series control systems and other automation equipment. The main function of this card is to perform logical control tasks. It can process and control the signal flow and instruction transmission in the system, and is a key component in industrial automation and process control systems.
Product Features
Logical control function:
The card processes control signals through built-in logic circuits, executes various decisions and instruction processing, and ensures the smooth operation of the system according to predetermined logic.
High precision data processing:
Provide high-precision data processing capabilities, support real-time computing and signal conversion to ensure system efficiency and stability.
High reliability:
Designed for harsh industrial environments, it has high anti-interference and durability, ensuring long-term stable operation.
Flexible signal interface:
Provide multiple input/output interfaces, supporting different types of signal transmission, including digital, analog signals, etc.
Modular design:
Plug in card design facilitates integration, installation, and replacement in control systems.
technical specifications
Working voltage:
Supports 24V DC or 48V DC power input (specific requirements depend on system configuration).
Logical processing ability:
Internally contains processing units for executing complex logical operations and data flow processing.
Input/Output:
Supports input and output of multiple signal types, suitable for different industrial automation needs.
Typical I/O interfaces include digital inputs, digital outputs, and analog inputs/outputs.
Work environment:
Temperature range:- 20 ° C to+70 ° C.
Humidity range: 0% -95% (without condensation).
Interface type:
Multi pin connector, used to connect other modules or external devices in the system.
Size and installation:
Usually with standardized dimensions, it can adapt to the slots of GE Speedtronic systems for easy installation and replacement.
2.產 品 展 示
