GE IC3600SOSF1示波器卡 PDF資料
1.產 品 資 料 介 紹：
中文資料：
GE IC3600SOSF1 示波器卡是通用電氣 (GE) Speedtronic 系列工業控制系統中的一種專用模塊，設計用于信號分析、波形捕獲和系統性能監控。此模塊的核心功能是提供實時信號顯示和診斷功能，是渦輪控制系統中關鍵的調試和監控工具。
產品概述
- 型號：IC3600SOSF1
- 類型：示波器卡模塊
- 主要用途：
- 捕獲和顯示電氣信號波形。
- 診斷工業控制系統中的信號問題。
- 提供實時數據分析支持。
技術特點
實時信號捕獲：
- 能夠捕獲高速動態信號，適用于復雜的工業控制場景。
- 提供高分辨率的波形顯示功能。
多通道支持：
- 具備多個信號輸入通道，可同時監控多個信號源。
- 支持模擬和數字信號的混合處理。
模塊化設計：
- 便于集成到 GE 的 Speedtronic Mark 系列控制系統中。
- 采用標準接口，確保與其他模塊的兼容性。
工業級可靠性：
- 抗電磁干擾（EMI）設計，確保信號的完整性。
- 適用于高溫、高濕等苛刻工業環境。
診斷功能：
- 實現對控制系統的快速故障定位。
- 提供波形數據的歷史記錄，用于深入分析問題。
英文資料：
The GE IC3600SOSF1 oscilloscope card is a specialized module in General Electric's (GE) Speedtronic series industrial control systems, designed for signal analysis, waveform capture, and system performance monitoring. The core function of this module is to provide real-time signal display and diagnostic functions, and it is a key debugging and monitoring tool in the turbine control system.
Product Overview
model: IC3600SOSF1
Type: Oscilloscope card module
Main purpose:
Capture and display electrical signal waveforms.
Diagnose signal issues in industrial control systems.
Provide real-time data analysis support.
Technical features
Real time signal capture:
Capable of capturing high-speed dynamic signals, suitable for complex industrial control scenarios.
Provide high-resolution waveform display function.
Multi channel support:
Equipped with multiple signal input channels, capable of monitoring multiple signal sources simultaneously.
Support mixed processing of analog and digital signals.
Modular design:
Easy to integrate into GE's Speedtronic Mark series control system.
Adopting standard interfaces to ensure compatibility with other modules.
Industrial grade reliability:
Anti electromagnetic interference (EMI) design ensures signal integrity.
Suitable for harsh industrial environments such as high temperature and high humidity.
Diagnostic function:
Realize rapid fault location of control systems.
Provide historical records of waveform data for in-depth analysis of problems.
2.產 品 展 示
