ABB P8151B單元處理器 PDF資料
1.產 品 資 料 介 紹：
中文資料：
三重模塊冗余 (TMR)
- 集成三重模塊冗余架構，確保系統在單點故障下持續運行。
- 每個模塊獨立運行并實時進行投票機制，以提高可靠性。
高性能處理
- 配備高速處理器，支持復雜邏輯運算和實時任務管理。
- 可執行大量 I/O 操作和控制算法，適應復雜的工業過程。
可靠性與可維護性
- 支持熱插拔，方便在線維護和模塊更換。
- 內置故障檢測與隔離機制，確保系統可靠運行。
強大的通信能力
- 支持多種工業協議，易于集成到分布式控制系統 (DCS) 中。
環境適應性強
- 適用于惡劣工業環境，具有抗振動和抗電磁干擾能力。
3. 技術規格
處理器:
- 高速 32 位或更高性能處理器
- 支持多任務操作和實時數據處理
內存:
- 支持用戶程序和實時數據的存儲
- 配備非易失性存儲器，用于日志和系統狀態保存
通信接口:
- 串口: RS-232、RS-485
- 網絡接口: 以太網支持
- 支持工業協議: Modbus TCP、EtherNet/IP、Profibus 等
電源需求:
- 24V DC 工業標準電源輸入
- 支持冗余電源配置
環境適應性:
- 工作溫度: -20°C 至 +70°C
- 抗振動、沖擊和電磁干擾
安裝方式:
- 模塊化設計，支持 19 英寸機架或定制外殼安裝
英文資料：
Triple Modular Redundancy (TMR)
Integrate triple module redundant architecture to ensure continuous operation of the system in the event of a single point of failure.
Each module runs independently and has a real-time voting mechanism to improve reliability.
High performance processing
Equipped with a high-speed processor, supporting complex logical operations and real-time task management.
Capable of performing a large number of I/O operations and control algorithms, adapting to complex industrial processes.
Reliability and maintainability
Support hot swapping, convenient for online maintenance and module replacement.
Built in fault detection and isolation mechanism ensures reliable operation of the system.
Powerful communication capability
Supports multiple industrial protocols and is easy to integrate into distributed control systems (DCS).
Strong environmental adaptability
Suitable for harsh industrial environments, with anti vibration and anti electromagnetic interference capabilities.
3. Technical specifications
Processor:
High speed 32-bit or higher performance processor
Support multitasking operations and real-time data processing
Memory:
Support storage of user programs and real-time data
Equipped with non-volatile memory for logging and system state storage
Communication interface:
Serial port: RS-232、RS-485
Network interface: Ethernet support
Supporting industrial protocols: Modbus TCP, EtherNet/IP, Profibus, etc
Power requirements:
24V DC industrial standard power input
Support redundant power supply configuration
Environmental adaptability:
Working temperature:- 20 ° C to+70 ° C
Resistance to vibration, impact, and electromagnetic interference
Installation method:
Modular design, supporting 19 inch rack or customized shell installation
2.產 品 展 示
