System Controller Select Header (J3)
Header J3 allows you to select the MVME147 as system controller.
With the jumper removed, the module is not used as system
controller. The module is shipped with the jumper installed
(system controller). Serial Port 4 Clock Configuration Select Headers (J8, J9)
Serial port 4 can be configured to use clock signals provided by the
TRXC4 and RTXC4 signal lines. Headers J8 and J9 on the MVME147
module configure part of the clock signals. The remaining
configuration of the clock lines is accomplished using header J15 on
the MVME712M module. Refer to the MVME712M Transition
Module and P2 Adapter Board User's Manual for header J15
configuration. The module is shipped with the jumper on pins 2
and 3 of J8 (receiving RTXC4), and on pins 1 and 2 of J9 (driving
TRXC4).Installation Instructions
When you have configured the MVME147’s headers and installed
the selected ROMs in the sockets as described previously, install the
MVME147 module in the system as follows:
1. Turn all equipment power OFF and disconnect the power
cable from the AC power source. Connecting modules while power is applied may result
in damage to components on the module.Dangerous voltages, capable of causing death, are
present in this equipment. Use extreme caution when
handling, testing, and adjusting.
2. Remove the chassis cover as instructed in the equipment
user's manual.
3. Remove the filler panel(s) from the appropriate card slot(s) at
the front and rear of the chassis (if the chassis has a rear card
cage). If the MVME147 is configured as the system controller,
install it in the left-most card slot (slot 1) to initiate the bus
grant daisy-chain correctly. The MVME147 is to be installed
in the front of the chassis; the MVME712 transition module
may be installed in the front or rear of the chassis.
Note Every MVME147 is assigned an Ethernet station
address. The address is $08003E2xxxxx where xxxxx is
the unique number assigned to the module; i.e., every
MVME147 has a different value for xxxxx.
Each Ethernet station address is displayed on a label
attached to the MVME147’s backplane connector, P2. In
addition
